G950CL

Product Description

Compact, light and portable gasoline generator

For entertainment, emergency and home use.

Spark arrestor keep the generator running safer

Overload protection for safe running

Full frame protection for easy transportation and carry

Economical, low fuel consumption

Continuous stable running 8 hours running without refueling

Easy maintenance with brush-less alternator and electronic ignition

Standard configuration of voltmeter enables convenient use.

AC/DC circuit breaker ensure safety for its overload and shock circuit protection.

Super quiet muffler with spark arrestor reduce engine noise.

Spanish stickers for reference in South American countries.

Smart generator suitable for picnic,camping

Strong Ariti-Vibration feet

Overload circuit breaker

ISO,CE,GS,UL,GS certificate

One year warranty with free spare parts

Features
Specs

Digital Control Panel.
The new gasoline genset model is equipped with digital control system and remote control. Some control units of the generator sets are on the multi-function display. .
Real-time Data Display.
A monitor of the panel will display the real-time working data of the generator set such as its output voltage, Frequency running time, battery voltage etc. Besides, the running trouble of the generator will also be displayed on the panel. .
Low Oil Alarm System.
Before the oil level drops to the limited level, the generator set will top automatically. The whole set can be restarted only if the oil is refilled.
New AVR .
The AVR (Automatic Voltage Regulator) not only can smooth the output but also can provide reasonable protection against.
The overload of the whole set, thus avoid damage to the set. .
Electrical Starter.
A convenient electric starter gets the new gasoline generator up and running quickly

Generator Model	G950CL
Type	Single-phase, three-phase, synchronous alternator;
Frequency (Hz)	50	60
Speed (rpm)	3000	3600
Max.ont.A.C output (w)	800	950
Cont.A.C output (w)	650	800
Voltage (v)	110; 120; 220; 230; 240; 220/110; 240/120.
D.C output (v)	12V 8.3A
Power factor (%)	100
Excitation system
Engine model
Type	2-Stroke,Reed valve forced, Air-coolde,sing cylinder
Displacement(cc)	87	87
BoreXstroke (mm)	54X38	54x38
Engine Speed (rpm)	3600	3600
Max.output (hp)	1.65	1.65
Cont.output (hp)	1.5	1.5
Combustion system	Forced Air
Governor system	Centrifugal weight system
Starting system	Recoil starter or Electric Starter
Lube oil capacity (L)	0.75	0.75
Fuel tank capacity(L)	4.2	4.2
Cont.working time(h)	6.5	6.5
optional configuration	************
Noise lvevk (db)	64dB(A)at 4 mts	64dB(A)at 4 mts
Package Dimension and Weight
Dimensions LXWXH (mm)	395×345×365	395×345×365
Net/Dry weight (kg)	23	23
