| Model | WD-HP30D(E) |
| Suction*delivery (mm) (inch) | 80*80/3*3 |
| Total Head (m) | 80 |
| Max. suction head (m) | 8 |
| Max capacity (m3 /h) | 48 |
| Suction Lift: | 8m |
| Self-Priming time(s/4m): | 15s |
| Max Speed: | 3600rpm (adjustable) |
| Engine Model | 192FE |
| Type | OHV Single-cylinder、vertical、air-cooled、4-stroke、direct injection |
| Bore×Stroke (mm) | 92x75 |
| Displacement(cc) | 499 |
| Compression ratio | 19:01 |
| Rated power/ Rated speed (Hp/r/min) | 8.2/3000 11/3600 |
| Max power/ Max speed (Hp/r/min) | 9.0/3000 13/3600 |
| Lubricating system | Pressure splashed |
| Starting system | Recoil starter/Electric starter |
| Fuel type | 0#、-10#、-20# diesel |
| Fuel tank capacity | 5.5L / 1.4Gal |
| Fuel consumption (g/hp.h/r/min) | 206/3000 215/3600 |
| Lube oil type | CD grade or SAE 10W-30, 15W-40 |
| Lube oil capacity (L) | 1.65L / 0.44Gal |
| Starting motor capacity (V、kW) | 12V 0.8kW |
| Charging generator capacity (V、A) | 12V 3A |
| Battery capacity (V、Ah) | Above 12V 20Ah |
| Overall dimension（L×W×H）mm | 620*520*580 |
| Dry weight(kg) | ≤77（Recoil starter） ≤84（Electric starter） |
